Description
Specification
Method of Detection : Electrochemical sensor for O2
Range Available : 0-30% scalable
Resolution : 0.01%
Accuracy & Repeatability : ± 1% of FS
Drift : <2% of full scale per month
Response Time (T-90) : ≤30 seconds
Display : Touch Screen
LCD
LED
Power : 80 to 230 VAC 50 Hz
Power Consumption : 8 Watts
Digital Output : RS485 with MODBUS Protocol
Analog Output : 4-20 mA (max load resistance upto 500 Ω
Relay Output : 2 nos. of potential free contacts
Humidity : 5-95% RH
Ambient Temperature Range : 4 to 50ºC
Flow Meter : 0.1-1 LPM
Enclosure : Wall, Panel, Rack & Table Top
Sample Connection : 1/4 inch S.S. Connection
Area Classification : General Purpose
