Description
iO 1000 1 loop, expandable to 4, Class A or B (Styles 4, 6, 7), each loop supporting up to 250 device addresses (125 detectors and 125 modules max.).
Addresses 1 to 125 are for detectors and addresses 126 to 250 are for modules
Maximum T-taps/loop: 1244 Class B (Style Y) or 2 Class A (Style Z)
6.0 A FWR total at 120/230 VAC 60 Hz
5.0 A FWR total at 230 VAC 50 Hz
2.5 A FWR each max. per circuit
120 VAC, 60 Hz, 2.0 A max.
230 VAC, 50-60 Hz, 0.97 A max.172 mA 267 mA 32 max.
8 drops max., RS-485 Class A or B
Data line length: 4,000 ft. (1,219 m)
* Auto-programming speeds installation time
* Supports Signature Series intelligent modules and detectors
* Combines the Signature intelligent releasing module with
Signature multisensor detectors for reliable fire suppression
* Form C contacts for alarm and trouble, Form A for supervisory
* Electronic addressing with automatic device mapping
* Optional Ethernet port for diagnostics, programming and a variety of system reports
* Two programmable switches with LEDs and custom labeling
* Supports Genesis horn silence over two wires, and UL 1971-compliant strobe synchronization
* Class B or Class A wiring
* Ground fault detection by module
* Supports up to eight serial annunciators, (LCD, LED-only, and graphic interface)
* Can use existing wiring for most retrofit applications
* Upload/download remotely or locally
* Two-level maintenance alert reporting
* Pre-alarm and alarm verification by point
* Adjustable detector sensitivity
* 4 x 20 character backlit LCD display
* Optional earthquake hardening: seismic Importance Factor 1.5
* Standalone operation
* Alarm ON command manually activates alarm condition
